Frequency-doubled diode-pumped disk lasers
Our trusted 532 nm laser sources with up to 8W continuous-wave output power for proven applications in medicine, illumination and signaling
Jenoptik has pioneered development and commercialization of diode-pumped thin disk laser technology and has over 25 years experience in the design and fabrication of diode-pumped solid state lasers.
With more than 25.000 units installed, our cw-532 nm thin disk lasers are proven in the field for a variety of applications such as ophthalmology, dermatology, veterinary medicine, laser projection and quality control.
Operation of our 532 nm thin disk lasers relies on TEC-controlled laser diode pump sources from our in house-fab, Nd:YVO4 gain crystals and TEC-controlled internal frequency doubling LBO crystals. Compared to other solid-state laser technologies, thin disk lasers offer highest electro-optical efficiency, water-less cooling of the gain medium and high beam quality (M² ~ 5) due to suppression of thermal lensing. This enables us to serve applications in the medical field of laser-based-therapy with our proven and highly reliable JenLas® D2.x and JenLas® D2.mini series.
The miniaturized JenLas® D2.mini 2-8W with its industry-leading, lowest form-factor fits into the palm of your hand and exhibits a rugged, sealed OEM-design for easy integration into your medical laser system.
With more than 25.000 units installed, our cw-532 nm thin disk lasers are proven in the field for a variety of applications such as ophthalmology, dermatology, veterinary medicine, laser projection and quality control.
Operation of our 532 nm thin disk lasers relies on TEC-controlled laser diode pump sources from our in house-fab, Nd:YVO4 gain crystals and TEC-controlled internal frequency doubling LBO crystals. Compared to other solid-state laser technologies, thin disk lasers offer highest electro-optical efficiency, water-less cooling of the gain medium and high beam quality (M² ~ 5) due to suppression of thermal lensing. This enables us to serve applications in the medical field of laser-based-therapy with our proven and highly reliable JenLas® D2.x and JenLas® D2.mini series.
The miniaturized JenLas® D2.mini 2-8W with its industry-leading, lowest form-factor fits into the palm of your hand and exhibits a rugged, sealed OEM-design for easy integration into your medical laser system.
Your Benefits
Miniaturized green laser
nm
Years of experience
in laser technology
Installed thin disk lasers
thousand worldwide
Three levels of integration are available:
- JenLas® D2.mini 2-8W free-space
- JenLas® D2.mini 3/8 W FC: fiber coupling into 100 µm core, NA = 0.11 (standard))
- JenLas® MLS Green: fully integrated, i.e. including fiber-coupling, control electronics, cooling and functional safety features conforming with the IEC 60601 medical electrical equipment norm
Make use of our laser product portfolio to configure and co-develop with us the laser solution you need.
Do you have any questions? Our experts are happy to help.
